Can be paralleled up to 30MW of power

800 kW
Up to 90%
400-480 VAC
50/60 Hz
3-Phase, 4-Wire Wye
3.0 m (117 in)
7.5 m (295 in)
3.03 m (119 in)
Grid Connect – 15,200 kg (33,500 lbs); Dual Mode – 18,000 kg (39,700 lbs)
10.9 MJ/kWh (10,300 BTU/kWh)
280 ºC (535ºF)
5.3 kg/s (11.7 lbm/s)
Pipeline Natural Gas, Biogas (Landfill, Digester), LPG, Raw Natural Gas (Sour, Associated Gas)
